Может кому будет интересно...
Для PSF32GGLD3USB
По данным 'ChipGenius v4.00.0807 (Program 2015-08-07, Database 2015-02-01)'
--
Description: [F:]USB Mass Storage Device(Patriot Memory)
Device Type: Mass Storage Device
Protocal Version: USB 2.10 <- Hint: This device can run faster when plugged to a USB3.0 port
Current Speed: High Speed
Max Current: 300mA
USB Device ID: VID = 13FE PID = 5500
Serial Number: 070B64D99FB4CE68
Device Name: Patriot Memory
Device Revision: 0100
Product Model: Patriot Memory
Product Revision: PMAP
Controller Vendor: Phison
Controller Part-Number: PS2251-07(PS2307) - F/W 01.07.30 [2015-12-29]
Flash ID code: 983A9493 - Toshiba [MLC]
Tools on web: http://dl.mydigit.net/special/up/phison.html
==
По данным 'Flash Drive Information Extractor v8.7.0.597 (aka usbflashinfo)'
--
Volume: F:
Controller: Phison PS2307
Possible Memory Chip(s):
Toshiba TH58TFG8DDLTA20
Toshiba TH58TFG8DDLTA2D
Toshiba TC58TFG7DDLTA00
Toshiba TC58TFG7DDLTA0D
Memory Type: MLC
Flash ID: 983A9493 7651
Chip F/W: 01.07.30
Firmware Date: 2015-12-29
ID_BLK Ver.: 1.4.3.0
MP Ver.: MPALL v3.86.1B
VID: 13FE
PID: 5500
Manufacturer:
Product: Patriot Memory
Query Vendor ID:
Query Product ID: Patriot Memory
Query Product Revision: PMAP
Physical Disk Capacity: 30991712256 Bytes
Windows Disk Capacity: 30991679488 Bytes
Internal Tags: 2Q2P-SX9G
File System: NTFS
Relative Offset: 31 KB
USB Version: 3.00 in 2.00 port
Declared Power: 300 mA
ContMeas ID: 76ED-05-00
Microsoft Windows XP SP3 Build 2600
------------------------------------
http://www.antspec.com/usbflashinfo/
Program Version: 8.7.0.597
##
Для PSF256GGLD3USB
По данным 'ChipGenius v4.00.0807 (Program 2015-08-07, Database 2015-02-01)'
--
Description: [K:]USB Mass Storage Device(Patriot Memory)
Device Type: Mass Storage Device
Protocal Version: USB 2.10 <- Hint: This device can run faster when plugged to a USB3.0 port
Current Speed: High Speed
Max Current: 300mA
USB Device ID: VID = 13FE PID = 6000
Serial Number: 070B63905D99D092
Device Name: Patriot Memory
Device Revision: 0110
Product Model: Patriot Memory
Product Revision: PMAP
Controller Vendor: Phison
Controller Part-Number: PS2251-08(PS230 - F/W 05.02.55 [2016-01-15]
Flash ID code: 983C99A3 - Toshiba [TLC]
Tools on web: http://dl.mydigit.net/special/up/phison.html
==
По данным 'Flash Drive Information Extractor v8.7.0.597 (aka usbflashinfo)'
--
Volume: K:
Controller: Phison PS2308
Possible Memory Chip(s): Not available
Flash ID: 983C99A3 7A51
Chip F/W: 05.02.55
Firmware Date: 2016-01-15
ID_BLK Ver.: 1.4.2.0
MP Ver.: MPALL v5.3.00
VID: 13FE
PID: 6000
Manufacturer:
Product: Patriot Memory
Query Vendor ID:
Query Product ID: Patriot Memory
Query Product Revision: PMAP
Physical Disk Capacity: 247833034752 Bytes
Windows Disk Capacity: 247829888512 Bytes
Internal Tags: 2Q2P-SX9G
File System: NTFS
USB Version: 3.00 in 2.00 port
Declared Power: 300 mA
ContMeas ID: 76ED-06-00
Microsoft Windows XP SP3 Build 2600
------------------------------------
http://www.antspec.com/usbflashinfo/
Program Version: 8.7.0.597
Кстати, у PSF256GGLD3USB обе микросхемы памяти "сидят" на BGA.
